Tech Specs

MeCreator 2 is Geeetech`s latest desktop 3D printer with half-opened and box-type design.

Printing Specifications:
Print technology: FDM
Build volume: 160x160x160mm (6.3" x 6.3" x 6.3")
Printing precision：0.05mm
Positioning precision: X/Y：0.05mm. Z：0.02mm
Print Speed: 60-80mm/s
Filament diameter: 1.75mm
Nozzle diameter: 0.4mm
Filament type: ABS/PLA

Software:
Operating system: Windows/Mac/Linux
Control software: GT-Host Repetier-Host Printrun Cura
File format: .STL 3ds obj amf dae G-code

Temperature:
Max heated bed temperature: About 110 °C
Max extruder temperature: About 240°C

Electrical:
Power supply:
Input: 110V/220V 360W
Output：DC12V/15A
Control Board: GT2560B
Connectivity: USB SD card (support stand-alone printing)

Mechanical:
Chasis: metal sheet
Build Platform: Aluminum alloy plate+ heatbed
XYZ Rods: Wear-resistant stainless steel and lead screw (Z axis)
Stepper Motors: 1.8°step angle with 1/16 micro-stepping

Physical Dimensions and Weight:
Machine Dimension: 320x320x360 mm
Shipping box Dimension: 460x460x410mm
Machine Net weight: 9.05kg
Machine shipping weight: 17.5kg

Note:
If your printer is clogged here is the way to deal with this problem.You also can check the way on our listing pictures.
1.Find the Ejector pin
The ejector pin is the accessories came with the 3D printer.

2.Heat up the extruder.
Turn on the printer heat up the temperature until the temperature of heat bed is 55℃ the temperature of extruder is 200℃.

3.Pull out of the filament.
Press the pressure level and pull push the filament then pull it out of the extruder.

4.Clean the nozzle.
Press the ejector to make it go through the Tube until all the filament goes out of the nozzle.

Package list

1 x Mecreator2 3d printer
1 x 3 meter starter filament
