Tech Specs

Printing specifications:
Print technology: FDM
Build volume: 300 x180x180mm
Printing precision：0.05mm
Positioning precision: X/Y：0. 011mm Z：0.0025mm
Print Speed: 80-110mm/s
Filament diameter: 1.75mm
Nozzle diameter: 0.4mm
Filament type: ABS/PLA

Software:
Operating system: Windows/Mac/Linux
Control software: EasyPrint 3D
File format: .STL G-code

Temperature:
Max heated bed temperature: About 110 °C
Max extruder temperature: About 230°C

Electrical:
Power supply:
Input: 110V-240V
Output：DC24V/360W
Connectivity: USB SD card Wi-Fi
LCD: 4.3" color touch screen

Mechanical:
Chasis: metal sheet
Build Platform: heat-resistant glass+ heatbed
XYZ Rods: Wear-resistant stainless steel and lead screw (Z axis)
Stepper Motors: 1.8°step angle with 1/16 micro-stepping
Physical Dimensions & Weight
Machine Dimension: 470x350x395 mm

Package list

Packing Dimension: 590x490x510 mm Net weight: 16.5kg Shipping weight: 29.48kg
